| Product model | LED Point Light-A | LED Point Lights-B | ||
| Input Voltage(V) | DC24V | DC48V | DC24V | DC48V |
| Working Lifetime(Hour) | ≥50000 | ≥50000 | ≥50000 | ≥50000 |
| Lamp Body Material | ABS+PC | ABS+PC | ABS+PC | ABS+PC |
| IP Rating | IP67 | IP67 | IP67 | IP67 |
| LED light source | 3535RGB*4+2835RGBW*2 | 3535RGB*8+2835RGBW*2 | 3535RGB*4+2835RGBW*2 | 3535RGB*8+2835RGBW*2 |
| Display color | RGBW | RGBW | RGBW | RGBW |
| Power | 3W | 3W | 3W | 3W |
| Color temperature | 3000K 4000K 5700K | 3000K 4000K 5700K | 3000K 4000K 5700K | 3000K 4000K 5700K |
| Lamp size | 56mm(L)*41.5mm(W)*14mm(H) | 56mm(L)*41.5mm(W)*14mm(H) | 56mm(L)*41.5mm(W)*14mm(H) | 56mm(L)*41.5mm(W)*14mm(H) |
| Warranty(Year) | 3-Year | 3-Year | 3-Year | 3-Year |
| control method | DMX | DMX | DMX | DMX |
| Gray scale | 16Bit | 16Bit | 16Bit | 16Bit |
| Beam angle | >120 | >120 | >120 | >120 |
| work temp | -20-60 | -20-60 | -20-60 | -20-60 |
| store temp | -40-75 | -40-75 | -40-75 | -40-75 |
1. High grayscale: 16bit grayscale level, smooth display, and rich colors;
2. Control: DMX512 control mode;
3. Multi voltage: covering working voltages of DC24V and DC48V;
4. Multiple mechanisms: support networking synchronization and asynchronous card insertion linkage mechanism;
5. Multiple spacing: standard spacing of 4 lights/m and 6 lights/m, supporting customized spacing;
6. Easy to install: compact in size, flat mounted with profiles, easy to install and maintain;
7. Standardization: Standard male and female plug-in foolproof wiring, standardized components, waterproof and foolproof, easy to operate and maintain;
8. Unification: Black light, black glue, black line, black glue head, gray light, white glue, gray line, gray glue head, with a unified and beautiful appearance;
9. High protection: The protection level is IP67, which not only adopts the double-sided three-dimensional non dead angle glue filling process, but also adopts the ultrasonic welding process in the manufacturing process, and adopts a secondary waterproof design;
10. High reliability: UV resistant, flame retardant V0 resistant, with a working life of 50000 hours.
